ScreenBeam | 1100 Plus

Flexible, high-performing wireless presentation and Unified Communications platform enabling hybrid meeting spaces.

ScreenBeam solves the challenges of delivering the best in-room experience combined with the most flexible UC implementation by integrating Bring Your Own Meeting (BYOM) into our award winning ScreenBeam 1100 Plus platform!

Bring Your Own Meeting with ScreenBeam Conference

Hybrid meetings requires places for safe collaboration between remote and in-person participants. ScreenBeam Conference software is included FREE with every ScreenBeam 1100 Plus to add support for all major web conferencing services including Teams, Zoom, GoToMeeting, Webex, and more. Users can wirelessly connect to the room display and peripherals. With ScreenBeam Conference gain flexibility beyond that of a traditional UC room system without the complexity or cost.

The ScreenBeam 1100 Plus delivers best-in-class wireless presentation.

Works with Miracast™, AirPlay™ and GoogleCast™ providing native wireless connections across all popular devices. Users can wirelessly share and mark-up content on the room display without first downloading an app, or finding the right dongle or cable. It connects to both internal and guest networks simultaneously without compromising security. Plus, HDMI input is available for older devices without wireless capability, integrated digital signage, and much more.
Catalog number: SBWD1100P

Flexible deployment options reduce complexity and lower capital costs

Three separate network interfaces supporting both internal and external networks in a single device. Presenter and guest connect using Miracast™, local Wi-Fi mode or network providing more flexibility for different network policies and deployment needs.

No apps to install and maintain, or dongles or cables required

Support for native wireless display protocols means users can wirelessly present from any device without having to install and maintain an application, or use a dongle or cable.

Integrate ScreenBeam wireless display with a UC system

Merge these two technologies into a single, collaborative experience of wireless display and UC conferencing for on-site and remote participants. Plug an HDMI cable from the ScreenBeam output into the HDMI input of your UC appliance. Learn more here.

Single device for both wired and wireless connections

Combines wireless display and HDMI switching in a single device. The new HDMI Input eliminates the need for an HDMI switch so rooms are fully functional for wired and wireless connections.

Multi-Network Support

No need to choose an internal or external network connection for your wireless display solution. ScreenBeam can connect to both simultaneously without compromising the security of your internal network.



Ghost Inking™ removes any wireless inking latency

Wirelessly markup content on the room display using Microsoft Windows Ink native in all Microsoft Office 365 apps – then store and share with everyone in the room instantly. Plus, Ghost Inking™ technology removes any wireless inking latency for a more intuitive and natural pen-to-paper experience.

Digital Signage for employee and guest communications

Idle displays in conference and other meeting rooms can be employed to transmit employee and guest communications with integrated HTML-based digital signage capability.



Multi-View allows up to four client devices to share content on-screen

Whether in-room or off-premise, as many as four participants can share content simultaneously during a meeting making it easier for real-time editing of materials.




Quick Switch Mode to switch between presenters without disconnecting

Presenters do not need to disconnect to allow the next presenter to assume control eliminating time-wasting delays and keeping meetings on track.

Multi-user and role-based central management of devices

Every ScreenBeam 1100 Plus includes Central Management System (CMS) Enterprise software to monitor and manage ScreenBeam receivers using a standard web browser, and support multi-user and role-based access for large deployments with multiple sites and administrators.




Three levels of security for the active connection

Connection level security support for most enterprise network certificate-based security requirements. Session level security with AES128 encryption to ensure that content is not compromised. Plus, customizable PIN pairing options providing IT/AV departments control over the user connection models so only authorized users are able to connect to the receiver.




Technical Specifications

Hardware

Video
• H.264 compression
Audio
• LCPM 2.0
Resolution1
• Up to 4K@30Hz

Ethernet
• 10/100/1000-BASE-T RJ-45 LAN

Wireless
• Miracast and Local Wi-Fi Mode: 802.11ac dual-band 3×3 MIMO
• Network Bridge: 802.11ac dual-band 2×2 MIMO
Authentication
• WPA-PSK (TKIP)

Protocol
• WPA2-PSK (AES)
• PEAP-MSCHAP V2
• EAP-TLS

Interface
• 1 x HDMI Input
• 1 x HDMI Output
• 2 x USB 2.0 Host Type-A
• 1 x USB 3.0 Host Type-A
• 1 x Analog 3.5mm audio output
• 1 x DC Power Jack

Content Protection2
• HDCP 2.x

Power
• Input: 12VDC, 3A
• Consumption: 8.4W (typical), 36W (peak)

Dimensions
• 8.66 x 5.66 x 1.47 inch (220 x 144 x 37.5 mm)

Operating temperature
• 0º – 40º C (32º – 104º F)

Storage temperature
• -20º – 85º C (-4º – 185º F)

Operating humidity
• 20 – 80% non-condensing

Storage humidity
• 10 – 90% non-condensing

Compatible OS/Device

Miracast P2P wireless display requires certified device with either:
• Windows 10 build 1607 (and later)
• Android 4.2 (and later)

Wireless display over network requires device with either:
• Windows 10 build 1709 (and later)
• Windows 7 (and later)
• macOS 10.10 (and later)
• iOS 11 (and later)
• Chrome OS 74.0.3729.159 (and later)

Language support
• English
• Simplified Chinese
• Traditional Chinese
• Japanese
• French
• German
• Dutch
• Korean
• Spanish
• Italian
• Russian

Others

Regulatory and compliance
• Approved: FCC and UL
• Pending:  CE, RoHS and C-Tick

Warranty
• Limited one year manufacturer hardware

1 Actual display resolution and quality depend on the wireless/network environment
2 Content protection is not available for Mac/iOS
