Hikvision Transparent LED Display Cabinet P.3.9 (Per SQM)
The Hikvision Transparent LED Display Cabinet P3.9 is a modular, high-brightness LED panel designed to deliver vivid content while maintaining see-through transparency. Perfect for retail shopfronts, showrooms, shopping centres, and corporate spaces, it allows dynamic digital content to be displayed on glass walls without obstructing natural light or visibility.
With its lightweight cabinet structure, high transparency ratio, and simple installation system, the P3.9 series provides a scalable signage solution. Sold per square metre (SQM), it can be configured into customised display sizes to meet project-specific requirements.
Hikvision Transparent LED Display Cabinet P3.9 – Modular LED Panels (Per SQM)
High-transparency LED display panels for retail, showrooms, and glass façade applications. Available now from DynamicCom, South Africa’s authorised Hikvision distributor.
🇿🇦 Available in South Africa from the Authorised Distributor!
Product Details
What’s in the Box
Transparent LED cabinet panel (P3.9, per SQM)
Power supply module
Signal/data cables
Mounting accessories
User guide
Technical Specifications
Display
Pixel Pitch: P3.9 (3.9 mm)
Resolution: Variable (dependent on total display size)
Transparency: Up to 60–70%
Brightness: 4000–5000 nits (outdoor visible)
Refresh Rate: ≥ 1920 Hz
Viewing Angle: 160° horizontal / 160° vertical
Colour Depth: 16.7M colours
Cabinet
Dimensions: Customised per project (modular per SQM)
Weight: Lightweight aluminium structure
Thickness: Slimline profile for glass mounting
Power & Connectivity
Average Power Consumption: ~300 W/m²
Max Power Consumption: ~800 W/m²
Input Voltage: AC 100–240 V
Data Input: Standard signal interfaces (Ethernet / controller)
Installation
Mounting Options: Hanging, fixed frame, or glass wall integration
Modular design for scalable installation
Quick-connect system for simplified maintenance
Key Benefits
High Transparency — Maintains visibility through windows and glass surfaces.
Bright & Vivid — Clear, dynamic visuals even in strong ambient light.
Customisable — Modular per SQM design for flexible project sizes.
Lightweight & Slim — Easy to install on glass façades or frames.
Energy Efficient — Low average power consumption for daily operation.
Local Warranty & Support — Supplied by DynamicCom, South Africa’s authorised Hikvision distributor.
Summary Table
Feature | Specification |
|---|---|
Pixel Pitch | P3.9 mm |
Transparency | 60–70% |
Brightness | 4000–5000 nits |
Refresh Rate | ≥ 1920 Hz |
Viewing Angle | 160° H/V |
Power Consumption | Avg. 300 W/m², Max. 800 W/m² |
Cabinet Type | Lightweight aluminium, modular per SQM |
Mounting Options | Hanging, fixed frame, glass wall |
